: Name: Frame Silicon Dispensing

Introduction: The product is specially designed for the sealing process of photovoltaic module frames. It adopts the front loading and rear unloading mode, equipped with universal wheels that can be moved and positioned at any time, and can be operated by one person. Integrated multi-dispensing detection system (front and rear detection positions of the valve) to diagnose needle abnormalities and glue defects in real time.

View details

: Name: Ribbon Lifting +Teflon Remover

Introduction: The products are dedicated to the production line of photovoltaic modules. The motor positioning and gantry shaft drive technology are used to achieve high precision (installation positioning accuracy ≤±0.2mm, repeated positioning accuracy ≤±0.05mm) and automatic lead finishing operations. The main body of the steel structure is stable and reliable, and it is equipped with a one-key switching intelligent correction system, which does not require manual intervention in the whole process, which significantly improves production efficiency and stability.

View details

: Name: Auto Glue Dispenser

Introduction: The products are dedicated to the production line of photovoltaic modules. The mechanical positioning method is used to achieve high-precision (gluing positioning accuracy±0.1mm) automatic gluing operation. The main body of the steel structure is stable and reliable, with the function of defective glue pattern detection. Fully automatic operation without manual intervention, and perfect adaptation to the width specifications of various components.

View details

: Name: Auto JB Placement

Introduction: The products are dedicated to the production line of photovoltaic modules. The automatic feeding of the material frame (positive and negative junction boxes) and the automatic feeding of the vibrating plate (intermediate junction box) are used to greatly improve the feeding efficiency; Through the precise installation of the secondary positioning platform and the robot (positioning accuracy ±0.2mm), the success rate of installation is significantly improved by the lead correction mechanism. The main body of the steel structure is stable and reliable, and the fully automatic operation does not require manual intervention, ensuring high stability production.

View details

: Name: Auto JB Soldering

Introduction: The product is specially used for the welding process of photovoltaic module junction box. The thermal resistance heating welding head is used to grab the welding wire, and the pre-welding positioning (accuracy ±0.5mm) and post-welding quality inspection are realized through the high-precision CCD imaging system, and the ±5°C closed-loop temperature control system is equipped to ensure the stability of welding, and all welding images are automatically saved to the PC system to realize the whole process of traceable intelligent welding operations.

View details

: Name: Auto JB Potting

Introduction: The product is specially used for the glue potting process of the junction box of photovoltaic modules. The Y-axis servo moving platform is used with the four-side centering mechanism to integrate the glue filling and transplanting function; The X/Z axis adopts a standard motion module, which has a long life and accurate positioning; It can be equipped with the function of glue quantity detection (accuracy ±3mm), the equipment has a compact structure, and supports personalized glue filling mode (with or without/height adjustable), which is perfectly adapted to the layout of the production line.

View details
